Optimized Lid

Lifting Aid

Horizontal 3D Beading

Solid 3D Front Beading

Reinforced Axle Suspension

ENLARGED INNER RADIUS

Wall Thickness

Innovative X-Comb Bar

Enlarged Corner Radii

Vertical 3D Beading with spring element

WERTSTOFFSAMMELBEHÄLTER

Grabber 240 L/H

2-RAD CONTAINER

Intensive development work based on practical tests and finite element calculations for the side loader filling are the foundations of this novel bin system. The innovative X-comb bar and the increased wall thickness and beading in critical areas increase stability and prevent deformation of the bin. Sprung elements and larger radii at high-stress points improve the elasticity of the Grabber 240 l recycling bin made of HDPE (s. image).

Enlarged corner radii from Ø 180mm to Ø 220mm
Higher wall thickness from 3.0 mm to 4.5 mm
17.8 times torsional rigidity. The patented X-construction is much more robust than the straight rib construction with the same material consumption.
The lid is shaped to suit the wind offers little attack surface.
The Grabber 240 L has been designed for high filling weights.
Enlarged corner radii at the side edges facilitate positioning and picking up of the bin by the grabber arm.
Extended radii at the bottom of the bin prevent bulk material clinging to it.
The ribbed design of the handle bar improves the handling of the bin.
Horizontal beading reinforces the bin against the hourglass effect.
The side bead design reinforces the bin when under the increased pressure influence generated by the grabber arm.
Increases trunk stiffness and absorbs the force during frontal containment of the container.
The axle suspension is designed as double ribs.

COLOR COMBINATIONS

produkte/wertstoffsammelbehaelter/2-rad-container/240_L_Grabber/kombinationen
Lid
Hull

For a color combination please select color.

produkte/wertstoffsammelbehaelter/2-rad-container/240_L_Grabber/kombinationen
